Page 2 - 4 Tank Sentinel Setup Programming Guide
Tanks – TANK DATA N Menu (C
ONTINUED
...
FROM
PREVIOUS
PA GE
)
TANK ALARM N To select Tank N ...
COPY (COPY is optional) Press the
M1
key.
COPY FROM TANK ALARMS X TO N
TANK 1 Select a tank to copy data from (use
M
key).
: Use
UP
/
DOWN
▲▼ keys to display tanks 5-8.
TANK 8 (The alarm copy function copies all alarm limits
COPY TANK ALARMS X TO N from Tank X to the current Tank # N)
PRESS ENTER IF YOU ARE SURE? Press
ENTER
to accept this data.
HIGH LIM
HIGH PRODUCT LEVEL LIMIT N
+96.0000
0.0 to 9999.0
Use keypad to input limit in inches or centimeters.
Press
ENTER
to accept this data.
H LIM OG (assign Alarm Limits to Output Group)
HIGH PRODUCT OUTPUT GROUP N (32 OGs available... see Worksheet #2 or #3)
NONE
Not assigned to an output Group (OG)
GROUP A-FF One OG selected (
A = 1
ST
OG, FF = 32
ND OG
)
ALL GROUPS All OGs selected
Use
UP/DOWN
▲ ▼ keys to choose an OG.
Press
ENTER
to accept this data.
HIGH HIGH N N refers to / represents a tank number
HI HI PRODUCT LEVEL LIMIT N
+96.0000
0.0 to 9999. (enter alarm limit)
Press
ENTER
to accept this data.
HH LIM OG N (assign Alarm Limits to Output Group)
HI HI PRODUCT OUTPUT GROUP N (32 OGs available... see Worksheet #2 or #3)
NONE
Not assigned to an output Group (OG)
GROUP A-FF One OG selected (
A = 1
ST
OG, FF = 32
ND OG
)
ALL GROUPS All OGs selected
Use
UP/DOWN
▲ ▼ keys to choose an OG.
Press
ENTER
to accept this data.
LOW LIM N N refers to / represents a tank number
LOW PRODUCT VOLUME LIMIT N
+0.0000
0.0 to 50000 (enter alarm limit)
Press
ENTER
to accept this data.
L LIM OG N (assign Alarm Limits to Output Group)
LOW PRODUCT OUTPUT GROUP N (32 OGs available... see Worksheet #2 or #3)
NONE
(A to FF, or ALL) Not assigned to an output Group (OG)
GROUP A-FF One OG selected (
A = 1
ST
OG, FF = 32
ND OG
)
ALL GROUPS All OGs selected
Use
UP/DOWN
▲ ▼ keys to choose an OG.
Press
ENTER
to accept this data.
LOW LOW N
LOW LOW PRODUCT VOLUME LIMIT N
+0.0000
+ 0 to 50000 (enter alarm limit)
Press
ENTER
to accept this data.
To Next Page
