tina46e1-b (2017-12) BPG402.om 9
BPG402-S, -SL
BPG402-SD, -SE, -SP
Adjustment range
1 ("SETPOINT")
2 ("SETPOINT A, B")
1×10
-9
mbar … 100 mbar
Setpoints adjustable via potentiometers,
one floating, normally open relay contact
per setpoint (→  19, 20, 39).
(Adjusting the setpoints via field bus
→ corresponding bus section)
Hysteresis 10% of the threshold value
Relay contact rating ≤30 V (dc), ≤0.5 A (dc)
Data rate
Data format
Connections (sensor cable connector)
TxD (Transmit Data)
RxD (Receive Data)
GND
9600 Baud
binary
8 data bits
one stop bit
no parity bit
no handshake
Pin 13
Pin 14
Pin 5
Function and communication protocol of the RS232C interface →  31
Fieldbus name DeviceNet
Standard applied
→  [7]
Communication protocol, data format
→  [1], [5]
Interface, physical CAN bus
Data rate
(adjustable via "RATE" switch)
125 kBaud
250 kBaud
500 kBaud (default)
"P" (125 kBaud, 250 kBaud, 500 kBaud
programmable via DeviceNet)
(→  [1])
Node address (MAC ID)
(Adjustable via "ADDRESS", "MSD",
"LSD" switches)
0 … 63
dec
(default = 63
dec
)
"P" (0 … 63 programmable via
DeviceNet, →  [1])
DeviceNet connector Micro-Style, 5-pin, male
Cable shielded, special DeviceNet cable,
5 conductors (→  21 and  [5])
Cable length, system wiring according to DeviceNet specifications
(→  [7], [5])
Fieldbus name EtherCAT
Standard applied, data format,
communication protocol
→  [11], [12]
Data rate 100 Mbps
Node address explicit device identification
Physical layer 100Base-Tx (IEEE 802.3)
EtherNET connector 2×RJ45, 8-pin, socket
<IN>: EtherCAT input
<OUT>: EtherCAT output
Cable shielded, 8-pin special Ethernet Patch
cable (quality CAT5e or higher)
Cable length ≤100 m
Switching functions
RS232C interface
DeviceNet interface
(BPG402-SD)
EtherCAT interface
(BPG402-SE)
