2 Interface Connection
For operating the temperature controlled CDGxxxD gauge via EtherCAT, two
interface cables conforming to the EtherCAT standard are required.
If no such cables are available, make two according to the following indications.
Ethernet Patch Cable Cable (CAT5e quality) with FCC68 connector.
 Pin assignment:
FCC68, 8-pin,
male, soldering side
Pin
Signal
Description
1
TD+
Transmission Data +
2
TD-
Transmission Data -
3
RD+
Receive Data +
4
nu
not used
5
nu
not used
6 RD- Receive Data -
7
nu
not used
8
nu
not used
Pin assignment of the D-sub 15-pin sensor connector according to the
respective operating manual (→  [1] … [8]).
8 1
Making an EtherCAT interface
cable
Cable type
Procedure
