4 | Installation INFICON
Caution
Dirt sensitive area
Touching the product or parts thereof with bare hands increases
the desorption rate.
· Always wear clean, lint-free gloves and use clean tools when
working in this area.
Mount the gauge so that no vibrations occur. The
gauge may be mounted in any orientation. To keep
condensates and particles from getting into the mea-
suring chamber preferably choose a horizontal to up-
right position. If adjustment should be possible after the
gauge has been installed, be sure to install it so that
the buttons can be accessed with a pin.
1 Remove the protective lid and connect the product to the
vacuum system.
Seal with centering ring
Clamp
Protective lid
Keep the protective lid.
