5.2.1
|
<ZERO> Adjustment
The zero can be adjusted via
· the <ZERO> button on the gauge
· the diagnostic port
· the digital input "Remote Zero": Apply the supply
voltage to pin 10 (15-pin) or to pin 7 (9-pin), pulse
>1 s … <5 s
· the RS232C interface
· an INFICON Vacuum Gauge Controller (VGC se-
ries)
While the gauge is being heated and/or under atmo-
spheric pressure, the zeroing function is locked in or-
der for operating errors to be prevented.
1 Evacuate the gauge to a pressure according to the table
below:
FS
Recommended final pressure for
zero adjustment
[Torr] [Pa] [mbar]
1100 mbar − <7×10
0
<7×10
‑2
1000 Torr <5×10
‑2
<7×10
0
−
500 Torr/mbar <3×10
‑2
<4×10
0
<4×10
‑2
200 Torr/mbar <1×10
‑2
<2×10
‑0
<2×10
‑2
100 Torr/mbar <5×10
‑3
<7×10
‑1
<7×10
‑3
50 Torr/mbar <3×10
‑3
<4×10
‑1
<4×10
‑3
20 Torr/mbar <1×10
‑3
<2×10
‑1
<2×10
‑3
10 Torr/mbar <5×10
‑4
<7×10
‑2
<7×10
‑4
5 Torr/mbar <3×10
‑4
<4×10
‑2
<4×10
‑4
2 Torr/mbar <1×10
‑4
<2×10
‑2
<2×10
‑4
1 Torr/mbar <5×10
‑5
<7×10
‑3
<7×10
‑5
0.5 Torr/mbar <3×10
‑5
<4×10
‑3
<4×10
‑5
0.25 Torr/mbar <1×10
‑5
<2×10
‑3
<2×10
‑5
0.1 Torr/mbar <5×10
‑6
<7×10
‑4
<7×10
‑6
0.05 Torr/mbar <3×10
‑6
<4×10
‑4
<4×10
‑6
