5 | Operation INFICON
Keep the button depressed
max. ø1.1 mm
· Fine adjustment of the zero adjustment value: Release
the button. Briefly press it again within 3s. The value
changes by one unit (push <ZERO> button in intervals of
1s).
· Change of direction (inverse ramp): Release the button.
Press and keep it depressed again within 3...5 s (the
flashing frequency of the <STATUS> indicator changes
briefly).
If the <ZERO> button is released for more than 5 s, the
gauge returns to the measurement mode.
The <STATUS> LED blinks green if the signal output is negative
(< -20mV).
