II.Hardware description
1. Power supply units (IDU)
All outdoor equipment is equipped with indoor power supply units. Exact type of
IDU which is used with each router model is specified in different models
description (see below).
IDU-5000-SCR
Front panel
Rear panel
Connection scheme for IDU-5000-SCR
