InfiNet Wireless R5000 Technical User Manual
Copyright © 2004-2006 by InfiNet Wireless Limited.
51
Example of rma test mode usage for manual mode:
rma rf4.0 test ab1 1400 mcast
Here:
• Test key word means that the test is performed in the manual mode
• Ab1 – system assigned name for the subscriber (do not mix with a
mnemonic subscriber name, see rma ab section). You can use
subscriber MAC-address instead
• 1400 – testing packet length
• mcast – multicast mode. If not specified the unicast packets are sent
Automatic RMA test modes
Two automatic test modes are available: using MAC-address (no registration)
and with registration on the BS. In the second case the subscriber searches for
the BS specified in its configuration and afterwards the testing starts using MAC-
address of the found BS.
Example (deferred test using MAC-address):
rma rf4.0 auto 00:00:0e:12:13:ac 2048 mcast
config save
Example (Base Station search test):
rma rf4.0 autobs 2048 mcast
config save
To disable automatic test modes, please type:
rma rf4.0 -autotest
config save
Load Meter
Load meter is a powerful tool that allows estimating the load of a system
interface specified by interface parameter. By default, the information is
displayed on one line and updated every second; the load is measured in
kilobytes.
Below picture shows the load meter output for the radio interface outputted in
line-by-line mode with one second interval.
