InfiRay GL35 User Manual

InfiRay Outdoor • Geni Series• Operating Manual www.infirayoutdoor.com
All rights reserved and shall not be copied and distributed in any form without written permission
Battery Type / Capacity
4400mAh Internal battery + 3300mAh Replaceable battery
Max. Operating Time (at t=22℃), h
★
10h
External Power Supply
5V (Type C USB)
Operational Characteristics
Max. Recoil Power on Rifled Weapon, m/s²
1000g (g=9.8 m/s
2
)
Degree of protection, IP code
IP67
Amount of built-in memory, Gb
32
Operating Temperature Range, ℃
-20~+50
Weight, g
＜730g
＜740g
＜780g
＜780g
Dimension, mm
225x63x90
235x63x90
238x70x90
248x70x90
★
The actual operating time depends on the intensity of using Wi-Fi, video recorder.
➢ Improvements may be made to the design and software of this product to enhance its features;
➢ If there is any change to the technical specifications of the product, it will be made without prior notice to the customer.

InfiRay GL35 Specifications

General

Resolution	384x288
Pixel Size	12μm
NETD	<40 mK
Lens	35 mm
Frame Rate	50 Hz
Sensor Type	Uncooled VOx Microbolometer
Focus	Manual
IP Rating	IP67
Display	OLED, 1024x768
Digital Zoom	4x
Battery Type	Li-ion
Spectral Range	8-14μm
Operating Temperature	-20°C to +50°C
Weight	450 g
