System, Environmental, and Power Specifications
For the Infoblox 2200 Series Platforms 15
System, Environmental, and Power Specifications
System specifications describe the physical characteristics of the Infoblox 2200 Series appliances. Environmental
specifications describe Infoblox 2200 Series temperature and moisture limits. Power specifications describe the
electrical range within which the appliance circuitry can operate.
System Specifications
• Form Factor: 2-U rack-mountable appliance
• Dimensions: 3.46” H x 17.36” W x 21.26” D (8.8 cm H x 44.1 cm W x 54.0 cm D)
• Weight: Approximately 40 pounds (18.14 kg)
• Ethernet Ports: MGMT, HA, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-T
• Serial Port: DB-9 (9600/8n1, Xon/Xoff)
• USB Ports: Two USBs 2.0/1.1 compliant
• LCD Panel: LCD (liquid crystal display) with input buttons
Environmental Specifications
• Operating Temperature: 41 to 95 degrees F (5 to 35 degrees C)
• Storage Temperature: -13 to 158 degrees F (-25 to 70 degrees C)
• Operating relative Humidity: 10% to 90% (non-condensing)
Electrical Power Specifications
• AC Power Supply: Dual input, 960 Watts
— Input Voltage.: 90 – 264VAC
— Input Frequency: 47 – 63 HZ
— Input Current: 4A max at 230V
— Inrush Current: 20A max at 230V
— Power Factor: > 0.94/230V 50 Hz
• Optional DC Power Supply: 960 Watts
— Input Voltage.: -36 - 72DC
— Input Current: 20A/ -36VDC, 10A/ -72VDC
— Inrush Current: 100A 2u sec max
