InFocus P111 - Bottom Panel Features; Bottom View of Projector

IN3144_IN3146_IN3148HD User’s Manual
— 6 —
Bottom view
ITEM LABEL DESCRIPTION SEE PAGE
1.
Ceiling support holes
Contact your dealer for information on mounting the projector on a
ceiling.
2.
Tilt adjustor Rotate adjuster lever to adjust angle position.
15
Note:
It is recommended to use InFocus ceiling mount p/n PRJ-MNT-UNIV. Refer to the installation guide
that comes with the mount for more information. The warranty does not cover any damage caused
by use of non-approved ceiling mount kits or by installing in an improper location.
1
25
m
m
[
4
.
9
"
]
1
4
4
m
m
[
5
.
7
"
]
54mm
[2.1"]
46mm
[1.8"]
31mm
[1.2"]
155mm
[6.1"]
82mm
[3.2"]
2
1
2
1
1
