Chapter 3 – Inputs-Outputs
XtrapulsPac Installation Guide
2.1.3 - XtrapulsPac-400/45 A, 100 A and 200 A
Design
Multi-axis
Available cooling versions
- Forced air (standard)
- Push-through (except for 200 A current rating)
- Cold Plate (except for 200 A current rating)
Operating power supply voltage
according to the drive parameters
100 to 800 V
DC
Undervoltage threshold
(1)
210 V
DC
Overvoltage threshold
(1)
910 V
DC
EMC filter on the mains power supply
External
Motor phase-to-phase output voltage
95 %  U
DC
/2 Vrms
Minimum phase-to-phase inductance
(1)
2 mH
Galvanic isolated auxiliary supply voltage
24 V
DC
+/- 15 % - 500 mA (without motor brake)
EMC filter on auxiliary supply
Integrated in the drive
(1)
These values correspond to the default configuration of the drive. For lower operating voltage, see Appendix
"Low operating voltage".
OUTPUT CURRENT RATINGS
TYPE
Max. output current
for 1 s (Arms) +/-5 %
(480 V
AC
)
Rated output
current (Arms)
(460 V
AC
)
Power losses
at rated current
(W)
Rated input
current (Arms)
(680 V
DC
)
UL
listed
Pac-400/45
45
22.5
345
26.3
yes
Pac-400/100
100
35
535
41
yes
Pac-400/200
200
75
1147
87.9
Complying
with the UL
standard
Maximum surrounding air temperature: 40°C.
