22
Chapter 3 – Inputs-Outputs
XtrapulsPac Installation Guide
2.2.4 - XtrapulsPac 400 V / 100 A dimensions
Dimensions are given in mm.
Standard version
BOTTOM VIEW
SIDE VIEW FRONT VIEW
TOP VIEW
