Perform operations as described in “connecting cables” chapter and
connect cables as follow:
Cables to plug:
Power lead
Telephone line
Ethernet cable
Serial link RS232 cable
If you need extra cables then cut undesired over-molded
section at
Install through-holes in the lead-through guides (as indicated
on the figure).
