Ingenico iSC250 - 7_3_4 Isc350 Peripheral Connectors and Host Interface Options

43/57 Telium Troubleshooting Guide / June 28, 2014
7_3_4 iSC350 Peripheral Connectors and Host Interface Options
The iSC350 PIN pad device may interface with a Host system using any of the following options:
RS-232
Tailgate (RS-485)
USB
Ethernet
Interface ports and peripheral connections are located on a panel at the back of the device. Peripheral connectors on this panel
include:
VGA connection
Audio output
Micro SD slot
Refer to the below image which shows the location of the interface ports and peripheral connectors.
