7_7_4 iWL250 Interface with Host System
In standalone mode the iWL250 may communicate to the Host system via a micro USB port, or via wireless (GPRS, 3G HSDPA, or
Bluetooth).
When connected with its base, communications options for the iWL250 include:
Dial-up modem (currently not used with RBA and UIA applications)
USB-A
RS-232
Ethernet modem
Ethernet 10/100 Base T
USB-B
Bluetooth Ethernet modem
7_8 iSelf Series Quick Reference
The iSelf Series of devices includes the iUP250, iUR250 smart card and MSR card reader, and the iUC150 contactless card reader as
shown in the following image. Configuration options include:
iUP250 integrated with iUR250 for MSR card and smart card transactions.
iUP250 integrated with iUC150 for contactless card transactions.
iUP250 integrated with iUR250 and iUC150 for MSR card, smart card and contactless card transactions.
Refer to the following image for this device family and its components.
