Installation manual
Installation 21
Chapter 3
Installation
Note: The installation of these control panels must be carried out in full compliance with national design
regulations, local fire regulations, laws and provisions in place, and in accordance with the relative
instructions and guidelines.
This Fire control panel should be located in a place that is:
• Dry
• Far from electromagnetic interference (electrical equipment, heating units, air-conditioning units, radio transmitters,
etc.)
The mounting location must satisfy all the requirements of the respective laws and bylaws in force for technical
installations.
The system must be installed in accordance with the following procedure:
1. Lay the cables
2. Connect all the devices to the BUS and to the detection lines.
3. Mount the Previdia-C-DIAL module inside the control panel (optional).
4. Mount the control panel to the wall
5. Complete the connections inside the control panel.
6. Power up the system.
7. Test the system
EN54: In order to guarantee the IMQ-safety systems certification and compliance to standard EN54-2:
• all the manual alarm buttons and fire detectors employed in the system must be associated with fire
detection and alarm functions.
• not more 512 detectors and/or manual call points can be connected.
• the wiring must be such that, in the event of any failure, the number of devices that remain insulated
can never exceed 32.
3.1 Mounting the control panel to the wall
1. Remove the securing screws and door (paragraph 2.2 - [A1]).
2. Remove the screws of the plastic housing containing the motherboard (paragraph 2.2 - [P]) paying attention to the
power-supply connection cables.
3. Open the holes at the side that you intend to use for the cable passage.
Note: In order to guarantee the IP30 protection grade, do not open any other holes..
4. Pull the cables through the open cable entries.
5. Using the holes on the back, mount the cabinet to the wall (paragraph 2.2 - [Z]).
The manufacturer strongly recommends the use of 8mm diameter minimum anchor screws (stop screws).
6. Complete the connections with the control panel terminals.
7. Replace the front plate.
