Inner Range Inception Security Controller Installation Manual. Rev. 6.0
© 2016 - 2023. Inner Range Pty Ltd.
19 www.innerrange.com
TROUBLESHOOTING.
If any problems are experienced during installation please check this troubleshooting guide for possible causes and
suggested solutions.
Problem
Possible Causes
Solution
System LED is RED
The VOUT, LAN or READER
positive (+) & negative (0V)
are shorted.
With the Inception panel powered, disconnect all VOUT, LAN
& READER connections.
Re-connect them one by one checking that the System LED
remains flashing Green after each connection.
If the System LED returns RED after plugging in one of the
above, there is a fault/short in the wiring of that power circuit.
Sirens sound after
disabling Service
Mode.
An area is armed with
unsealed inputs.
An input in an area is in the
tamper state.
The controller or a module
is detecting a tamper
(cabinet or siren)
Navigate to the Control Inputs page in the web browser &
look for inputs that are in the tamper or alarm state.
Navigate to the View Hardware page & verify the state of the
modules. If any modules are indicating tampers, fix the issue
or navigate to the Hardware page & edit the module to not
monitor that tamper on the Additional Components section of
the wizard.
Alarm LED is on
The configured alarm
reporting paths are incorrect
& Alarm events cannot be
sent via a network path to
the monitoring station.
Ensure a monitoring station account is configured for this
device.
If reporting via SkyTunnel, navigate to Network Settings &
ensure that the Ethernet, Wi-Fi & Skytunnel settings are
configured correctly.
Wi-Fi LED is turned
OFF when the Wi-Fi
Adapter is plugged in.
Wi-Fi has been disabled on
the Network Settings page,
or the adapter is not an
approved Inception Wi-Fi
Adapter or is not supported
in the Controller firmware.
Navigate to Network settings & check that Enable Wi-Fi has
been selected. Ensure the correct Wi-Fi Connection mode
type is selected. Ensure that an authorized Inner Range
Inception Wi-Fi Adapter is connected and is supported.
Upgrade firmware to V5.0.0 or later. See ‘Accessories List’
or contact your Dealer for Wi-Fi Adapter details.
Skytunnel LED is
OFF/Unable to
connect to Inception
panel via Skytunnel
No Internet Access.
Skytunnel connection has
not been correctly configured
Confirm the network has internet access. Navigate to
Network settings & ensure that Enable Web Access over
Skytunnel is checked.
Strobes or sirens are
not functioning
correctly.
The connected siren wiring is
shorted/not connected or is
not configured correctly.
Navigate to the Area Test page & manually test the sirens.
For those that do not work correctly, ensure the area
configuration is correct then check wiring.
Unable to login with
any user, or access is
restricted with all
users.
The installer user credentials
were lost, or a web profile
change has limited
everyone’s access
Perform an Installer User Password reset.
Review Events &/or
time scheduling is
wrong or appears out
of order.
Date & Time Settings are
incorrect
The time has been
manually set or the
configured NTP server is
not configured correctly.
Navigate to the Date & Time configuration page. In order to
set the time manually, click “Set Date/Time Manually”.
Once the dialog box appears either set the time using the
calendar or by clicking the “Get time from browser“. This will
sync the inception panels time to that of the device being
used to setup the system.
The input states are
backwards (active
when it should be
secure & vice-versa).
a) EOL Resistors are
incorrectly wired.
b) The device’s output is
Normally Open for secure &
closes for the active state.
If ‘a)’, rectify EOL wiring.
If ‘b)’, configure the Input as normal, then navigate to the
Inputs configuration page, select the input and set ‘Swap
Active States’ to “Swap Active & Secure States”.
The active and
tamper input states
are backwards.
a) EOL Resistors are
incorrectly wired.
b) The device requires the
active & tamper states to be
flipped.
If ‘a)’, rectify EOL wiring.
If ‘b)’, configure the Input as normal, then navigate to the
Inputs configuration page, select the input and set ‘Swap
Active States’ to “Swap Active & Tamper States”.
