20
Avoid placing the unit within 1 metre of radio and video
equipment.
Make sure that:
• the installation site of the unit must be chosen with
the utmost care to guarantee adequate protection
from shocks and consequent damage
• -
ance.
•
construction elements or power lines
• the appliance must be installed in a position where it
can be easily serviced
Provide the following:
• a drain and a water supply nearby
• a compliant power supply nearby
Preliminary warnings for R32
The appliance must be installed in well-ventilated
-
erant charge in the circuit.
The refrigerant charge means the total charge of
thecircuitgivenbythesumofthefactorycharge
andanyadditionalcharge.
Refer to the rating plate on the paired outdoor unit for
the amount of refrigerant gas loaded in the unit.
If the appliance is located in a poorly ventilated place,
precautions must be taken to prevent stagnation in the
event of leakage of refrigerant to avoid creating a risk
The appliance must be placed in room where there are
appliance in operation) and no sources of ignition (e.g.
an electric heater in operation).
Any ventilation openings must be kept free of obstacles.
Perform the following checks:
• carry out safety checks to ensure that the risk of com-
bustion is minimised
•
• delimit the area around the workspace
• ensure safe working conditions around the area by
Minimumoorarea
m (kg) Amin (m²)
1,8 Without limitations
2,0 3,81
2,2 4,61
2,4 5,49
2,6 6,44
2,8 7,47
3,0 8,58
3,2 9,76
3,4 11,02
3,6 12,36
3,8 13,77
4,0 15,26
4,2 16,82
4,4 18,46
4,6 20,18
4,8 21,97
5,0 23,84
5,2 25,79
5,4 27,81
5,6 29,91
5,8 32,09
6,0 34,34
6,2 36,67
1. m Refrigerant charge
2. Amin Minimum oor area
3�10 Installation minimum distances
The clearance zones for the installation and maintenance
-
es are necessary to allow for normal cleaning and mainte-
nance.
panels to be removed for routine and supplementary
maintenance operations.
