65

Models m.u.
5 7 9 12 15
Suction “SAE 5/8
Liquid “SAE 3/8
Sound data
Sound pressure dB(A) 30,0 30,0 30,0 31,0 31,0
Electrical data
Power Supply V/ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Indoor unit protection degree IPX2
Product dimensions and weight
Total widh mm 600 600 600 600 600
Total height mm 2000 2000 2000 2000 2000
Total depth mm 600 600 600 600 600
Empty weight kg 179,0 179,0 179,0 179,0 179,0
1. Water temperature in/out 30/35 °C; outdoor air temperature 7 °C; U.R. 85%
2. Value referred to the Average climate prole for supply temperature of 35 °C. Values in compliance with Regulation 811/2013.
3. Water temperature in/out 30/35 °C; outdoor air temperature -7 °C
4. Water temperature in/out 23/18 °C; outdoor air temperature 35 °C
5. (radiant application)
6. Water temperature out 12/7 °C; outdoor air temperature 35°C
7. (fancoil application)

Refer to the manual of the outdoor unit for data about
the refrigerating circuit.
