Chapter2TechnicalSpecificationsandElectricalInstallation
10
IS300 Model
Recommended Power
of Braking Resistor
Recommended
Resistance
Braking
Unit
Remarks
IS300T250-C-L 6.5 kW x 2 8 x 2 External MDBUN-90-T x 2
IS300T300-C-L 16 kW 2.5 External MDBU-200-B
Three-phase 480 V
IS300-5T002-C 150 W 300
IS300-5T003-C 150 W 220
IS300-5T004-C 250 W 200
IS300-5T005-C 300 W 130
IS300-5T010-C 400 W 90
IS300-5T015-C 500 W 65
IS300-5T020-C 800 W 43
IS300-5T030-C 1000 W 32
IS300-5T035-C 1300 W 25
IS300-5T040-C 1500 W 22
IS300-5T050-C 2500 W 16
Built-in -
IS300-5T070-C 3.7 kW 16 External MDBUN-45-5T
IS300-5T080-C 4.5 kW 16 External MDBUN-45-5T
IS300-5T100-C 5.5 kW 16 External MDBUN-45-5T
IS300-5T140-C 7.5 kW 12 External MDBUN-60-5T
IS300-5T170-C 9 kW 8 External MDBUN-90-5T
IS300-5T210-C 11 kW 8 External MDBUN-90-5T
IS300-5T250-C 6.5 kW x 2 12 x 2 External MDBUN-60-5T x 2
IS300-5T300-C 16 kW 2.5 External MDBU-200-D
IS300-5T370-C 20 kW 2.5 External MDBU-200-D
IS300-5T420-C 22 kW 2.5 External MDBU-200-D
IS300-5T460-C 12.5 kW x 2 2.5 x 2 External MDBU-200-D x 2
IS300-5T520-C 14 kW x 2 2.5 x 2 External MDBU-200-D x 2
IS300-5T580-C 16 kW x 2 2.5 x 2 External MDBU-200-D x 2
IS300-5T650-C 17 kW x 2 2.5 x 2 External MDBU-200-D x 2
IS300-5T720-C 14 kW x 3 2.5 x 3 External MDBU-200-D x 3
IS300-5T140-C-L 7.5 kW 12 External MDBUN-60-5T
IS300-5T170-C-L 9 kW 8 External MDBUN-90-5T
IS300-5T210-C-L 11 kW 8 External MDBUN-90-5T
IS300-5T250-C-L 6.5 kW x 2 12 x 2 External MDBUN-60-5T x 2
IS300-5T300-C-L 16 kW 2.5 External MDBU-200-D
1. " x 2" indicates that two braking units with their respective braking resistor are connected in parallel. " x
3" means the same.
2. The models in grey are customized (servo drive of water cooling).
