Inovance MD310 Series User Manual

3 Easy Setup
- 11 -
3�2 Step By Step Setup
■
Setup Flowchart
Check
nameplate and wiring
Refer to Chapters 1 and 2
Apply main power to AC drive
Get familiar with keypad
Set motor parameters
Set motor control mode
Perform motor tuning if it’s SVC control mode
Set frequency reference
Set operation mode
Set start mode and stop mode
Set acceleration and deceleration time
Set DI and DO if needed
Set startup frequency if needed
Set S-curve if needed
Set DC injection braking/pre-excitation if needed
Check motor rotation and machine travelling direction
Check motor current
RUN!
Set PI of velocity loop if it’s SVC controlling mode
Refer to User Manual
Refer to User Manual
1
2
3
4
5
6
7
8
9
10
11
12
13
