10
Keys on operation panel
Key Key Name Function
PRG
Programming Enter or exit Level I menu.
ENTER
Confirm Enter the menu interfaces level by level, and confirm the parameter setting.
Increment Increase data or function code.
Decrement Decrease data or function code.
Shift
Select the displayed parameters in turn in
the stop or running state, and select the digit to be
modified when modifying parameters.
RUN
RUN Start the AC drive in the keypad operation mode.
STOP
RES
Stop/Reset
Stop the AC drive when it is in the running state and perform the reset operation when it is in
the faulty state. The functions of this key are restricted by F7-02.
MF.K
Multifunction
Perform function switchover (such as quick switchover of command source or direction)
according to the setting of F7-01.
QUICK
Menu mode selection Perform switchover between menu modes according to the setting of FP-03.
Relevant parameters for operation panel setting
Function
code
Parameter Name Setting Range
F7-01 MF.K key function
selection
0: MF.K key disabled
1: Switchover from remote control (terminal or
communication) to keypad control
2: Switchover between forward rotation and
reverse rotation
3: Forward jog
4: Reverse jog
5: Individualized parameter display
N.A. 0 0
F7-02 STOP/RESET key
function
0: STOP/RESET key enabled only in keypad
control
1: STOP/RESET key enabled in any
operation mode
N.A. 1 1
FP-03 Parameter display
property
For user defined and user modified parameters
00: non of them will display
01: user defined parameters will display
10: user modified parameters will display
11: both of them will display
N.A. 00
