27
5.5 Group F4: input terminals
Function
Code
Parameter name Setting Range
Commission
F4-00 DI 1 function selection
(Standard on-board)
0 : No function
1 : Forward RUN (FWD)
2 : Reverse RUN (REV)
3 : Three-line Control
4 : Jog Forward (FJOG)
5 : Jog Reverse (RJOG)
6 : Terminal UP
7 : Terminal DOWN
8 : IGBT Enable
9 : Fault reset (RESET)
10: RUN Pause
11: Normally open (NO) input of external fault
12: Multi-reference terminal 1
13: Multi-reference terminal 2
14: Multi-reference terminal 3
15: Multi-reference terminal 4
16: Terminal 1 for acceleration/deceleration
time selection
17: Terminal 2 for acceleration/deceleration
time selection
18: Frequency source switchover
19: UP and DOWN setting clear
(terminal, operation panel)
20: Command source switchover terminal 1
21: Acceleration/Deceleration prohibited
22: PID pause
23: PLC status reset
24: Swing pause
25: Counter input
26: Counter reset
27: Length count input
28: Length reset
29: Torque control prohibited
30: Pulse input (enabled only for DI5)
31: Reserved
32: Immediate DC braking
33: Normally closed (NC) input
34: Frequency modification forbidden
35: Reverse PID action direction
36: External STOP terminal 1
37: Command source switchover terminal 2
38: PID integral pause
39: Switchover between main
X and preset frequency
40: Switchover between auxiliary frequency
source Y and preset frequency
41: Motor selection terminal 1
42: Motor selection terminal 2
N.A
1
F4-01 DI 2 function selection
(Standard on-board)
N.A
2
F4-02 DI 3 function selection
(Standard on-board)
N.A
12
F4-03 DI 4 function selection
(Standard on-board)
N.A
13
F4-04 DI 5 function selection
(Standard on-board)
N.A
14
F4-05 DI 6 function selection
(On-board expansion card)
N.A
0 8
F4-06 DI 7 function selection
(On-board expansion card)
N.A
0 15
F4-07 DI 8 function selection
(On-board expansion card)
N.A
0
F4-08 DI 9 function selection
(On-board expansion card)
N.A
0
F4-09 DI 10 function selection
(On-board expansion card)
N.A
