Unpacking Inspection
‑22‑
4 Unpacking Inspection
4.1 Unpacking Inspection
Check the following items upon unpacking.
Items
Description
Check whether the
delivered product is
consistent with your
order.
Check whether the servo drive model and specifications
comply with your order.
See the dimensions of the packing box in "
Table 4–1
"
on page
22
. The deliverables include the product, cushion, carton box,
and screw bag, as shown in "
Figure 4–1
"
on page 23
.
Check whether the
product is intact.
Check whether the product delivered is in good condition. If
there is any missing or damage, contact Inovance or your
supplier immediately.
Table 4–1 Dimensions of the outer packing box
SIZE
Servo Drive Model
SV660F****I
Outer Width
(mm)
Outer Height
(mm)
Outer Depth
(mm)
Weight
(kg)
A
S1R6, S2R8
250.0 90.0 195 0.96
B S5R5 225.0 90 205.0 1.17
C
S7R6, T3R5, T5R4
235.0 105.0 215.0 1.48
D
S012, T8R4, T012
235.0 130.0 225.0 2.02
E
T017, T021, T026
320.0 150.0 280.0 3.94
