8,000 BTU Window Air Conditioner
* Indicates extra hardware provided in a separate bag.
Air conditioner
Air conditioner support bracket
Side Arm Foam Block 2
Window Sash Lock 1
Window Sash Foam 1
Window Sealing Foam 1
Bracket Sealing Foam 1
Additional Side Arm Foam 2
Note: Save the carton and these instructions for future reference. The carton is the best way to store your air conditioner during the
winter or when not in use.
Mounting slot
Air outlet
Control panel
Air input
Main support
Rear cross brace
Left extension arm
Right extension arm
Spring push pin
Horizontal bracket
Angled support
arms
