21
8,000 BTU Window Air Conditioner
9 After making any final adjustments, insert the two cotter pins into the main support pin on both support brackets.
10 If necessary, cover the holes on the front of the bracket with bracket sealing foam.
Step 3: Installing your air conditioner on the support bracket
1 Measure the width of your window track (the vertical track your window slides up and down in). If it measures 1/2“ or
less, flip the anti-tip bracket so that the small end faces out, then continue with your air conditioner installation.
CAUTION: Do not leave your air conditioner unattended during installation.
Bracket sealing foam
Bracket sealing foam
This side faces indoors
Anti-tip bracket
To Next Page
