6 Cut bracket sealing foam strips to length and apply to the bottom of the bracket.
Step 2: Installing the support bracket
1 Open the window where your air conditioner is being installed.
2 Place the main support bracket into the window opening, making sure that the horizontal bracket and extension arms
are located on the indoor side of the window.
CAUTION: Maintain control of the bracket until the installation is complete.
Apply bracket
sealing foam
Bottom view
Apply bracket
sealing foam
Apply bracket
sealing foam
