www.insigniaproducts.com
23
8,000 BTU Window Air Conditioner
5 Using 1/4 in. and 1/2 in. type B screws, install the open window brackets with an “L” shaped screwdriver, if needed.
Step 4: Installing the sealing foam and anti-tip brackets
1 Measure the distance between the right side arm hinge and the closest part of the window frame. Add 1/4 in. to this
distance and cut the side arm foam block to width.
WARNING: Failure to install the open window brackets could cause injury or property damage.
CAUTION: Do not leave your air conditioner unattended during installation.
1/2 in. type B screw
1/4 in. type B screw
