www.insigniaproducts.com
22
2 Set your air conditioner on top of the support bracket, making sure that the grooves on the bottom of your air
conditioner align with the main supports. Using a level, check for proper tilt towards the outside.
3 Pull the window down into the slot on top of your air conditioner to help align it correctly. Keep the window partially
inserted into the slot to help support your air conditioner during installation.
4 Fold down both side arm hinges.
Side arm hinge
Side arm hinge
