CONNECTING WITH AN RF (COAXIAL)CABLE (GOOD)
The resolution of the video signal output is 480i for both RF and AV
connections, but AV gives better sound and signal quality. You will need an
additional coaxial cable if you use this setup option.
1. Connect your existing antenna cable to the RF IN jack on the converter
box. You may need to remove the antenna cable from the back of your TV
and connect it to the converter box.
2. Connect a coaxial cable (included) from the converter box’s RF OUT jack
to your TV’s ANTENNA IN jack. For best performance with this
connection, change the Audio Output option to Mono from Stereo (see
your TV’s user guide for more information).
3. Connect the AC adapter from the DC IN jack to a power outlet.
4. Turn on your TV and converter box.
5. See Setting initial setup options (on the next page) to finish setting
up your converter.
www.insigniaproducts.com
11
Digital to Analog Converter Box
