13
STEP 3: ASSEMBLING THE SEAT BACK (See FIGURE 3)
Required Hardware: Step 3
5x (# 11 ) Flat Head Socket Screws 2x (#56) Cross Head Screw
4x (#31) M8 * 16 Allen Head Bolt 4x (#33) M8 Flat Washer
2x (#15) Cross Head Screw 4x (#32) Spring Washer
Required Parts:
(# 1) Seat Back Tube Assembly (#35) Seat Pad, Charcoal
(#68) Seat Back Tilt Cover, Left (#69) Seat Back Tilt Cover, Right
Installing Seat Back Tube Assembly
A) Assemble Seatback (#1) onto Seat Slider Assembly.
Align lower holes and secure using 5x (#11) Flat Head Socket Screws
Installing Seat Back Tilt Cover
B) Secure Seat Back Tilt Cover – Left (#68) , on the user left side of the unit ,
with qty 1 (#15) Cross Head Screw.
C) Secure Seat Back Tilt Cover – Right (#69) , on the user right side of the unit ,
with qty 1 (#15) Cross Head Screw.
Installing Seat Pad
D) Secure seat bottom pad (#35) to Seat Slider Assembly using qty 4 Flat Washers (#33),
qty 4 spring washers (#32), and qty 4 M8x16mm Socket Screws (#31)
To Next Page
