CS3 Parts List
EXP
NO.
Part Number
Description
Qty/Item
1
RC804-360-002PZ
Back Pad Assembly
1
2
RC804-520-001
EMS 2 side-way flywheel
1
3
RC800-801-008A
Front Cover R
1
4
RC800-801-006A
Cover R
1
5
0116-306-028
Spring Washer φ6
4
6
0114-742-068
Cross Tap Screw with Big W
asher
6
7
RC800-561-005
Child Safety Lock
1
8
RC800-401-002SK
Seat Back Pad
1
9
BC830-881-006Q
Bottle
1
10
RC802-350-002
Heart Rate Handle Bar Assembly
1
11
0113-306-128
Flathead Socket Screw M6*12
9
12
RC804-630-001SKA
Pulse Connecting Wire
2
13
RC804-801-008
Disc
2
14
RC804-630-001SKB
Lower Control Board
1
15
0113-104-108
Cross Head Screw M4*10
18
16
0116-006-008
Flat Washer φ6
4
17
RC802-630-002SK
Cross Head Screw M5*10
4
18
0114-142-198
Cross Head Tap Screw
3
19
RC804-630-001SKC
Console
1
20
RC804-561-017
Aluminum End Cap
2
21
RC804-331-002PZ
Handlebar tube assembly R
1
22
0113-106-018
Cross Head Screw M6*10
6
23
BC680-801-010B
End Cap 2
2
24
0113-706-162
M6*16 Bolt
4
25
RC804-561-020
Curved Washer
12
26
0113-308-206
Flat Head Socket Screw
M8*20
12
27
0111-408-718
Carriage Bolt M8*70
4
28
30
Table of Contents
Table of Contents
1
Important Safety Notice
2
Care and Maintenance
2
Contents of Packaging
3
Warning/Patent Label Placement
4
Hardware Pack
5
Assembly
6
Frame Staibilizer Assembly
7
Installing Stabilizers
7
Installing Seat Adjustment Handles
7
Swing Arm Assembly
9
Handle Assembly
10
Assembling the Seat Back
13
Installing Seat Back Tube Assembly
13
Installing Seat Back Tilt Cover
13
Installing Seat Pad
13
Mast Assembly
15
Attaching the Mast
15
Attaching the Bottle Holder
15
Attaching the Heart Grip
16
Attaching the Console
16
Product Features
17
Slider Stop
17
Engaging the Child Safety Lock Assembly
18
Console Details
18
Handle Orientation
19
Seat Back Orientation
19
Technical Specification
20
Wearing the Heart Rate Sensor
20
Computer Operation Features
21
Basic Operation
21
Standard Programs
22
Focus Programs
23
Heart Rate Programs
24
Heart Rate Program Setup
25
Focus Program Setup
25
Users
26
Change User Settings
27
User Data
28
Parts List
29
Alternative Plugs
33
Exploded Diagrams
34
