119
Ancillary parts
Product Support: www.instron.com
Mechanical tensioner kit A636-160 1 Installation kit for 30 kN and
50 kN load cells.
Refer to “Install the load cell” on
page 76
M16 x 100 screw 201V85 1 Load cell installation screw and
washer combinations.
Refer to “Install the load cell” on
page 76
M16 x 80 screw 201V83 1
M10 x 140 screw 71-63-1169 1
M10 x 120 screw 201V632 1
M10 x 90 screw 201V62 1
M10 x 70 screw 201V60 1
M10 x 40 screw 201V57 3
M10 washer 610J9 3
M17 washer 610K12 1
M16 washer 610J12 3
Pin 3mm diameter, 10mm long 705K84 3 Load cell anti-rotation pin
Pin 3mm diameter, 12mm long 705K85 3 Load cell anti-rotation pin
Locating ring T1335-1048 1 Locating ring for base - 40mm
diameter for M30 thread
Locating ring adapter T604-101 1 Adapter for load cell locating ring -
40mm/20mm - used for 2530
Series load cells (10kN, 30kN,
50kN)
M10 spacer T604-90 1 Use with M10 screws for load cell
attachment
Fuse, 10A Time lag, 5 x 20mm
glass high surge
27-2-233 2 Protection from electrical surges
Compression spring 66-4-23 1 Compression springs for different
base adapters.
Compression spring 66-4-5 1
Compression spring 66-5-6 1
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame
and installation of accessories
Table 10. Ancillary parts (Continued)
Description
Part
Number Quantity Purpose
