Chapter: Maintenance
120 M10-17318-EN
Thin open-ended wrench,
16mm/17mm
P632-482 1 Tool for adjustment of feet on load
frame
Combination wrench, 19mm P632-484 1 Tool for adjustment of feet on load
frame
Tool socket driver 14 mm key 80-3-50 1 Used for installation of 2580-10kN
load cell
8mm bit - 1/2in drive 80-3-13 1 Tool for tightening M10 screws
Torque wrench 80-9-9 1 Provides correct installation torque
for load cell and base adapter
attachment screws
Retainer clip for 0.5 in diameter
pin
T1223-1053 2 Prevents the grip coupling pin from
sliding out during testing
Accessories slot T-nut T1697-1307 3 Installing accessories onto the
column cover
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
3 MTS Ground cable A712-213 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Converter Type D to Type O 2501-346 1 Allows use of accessories with
Type O interface.
Cable Ethernet CAT5E 7 ft P636-196 1 Connects frame to computer.
Table 10. Ancillary parts (Continued)
Description
Part
Number Quantity Purpose
