Diagram “P”
+ Voltage output
-Output
+ Current output
NO
AL4
NCNO
AL3
NCNO
AL2
NC
AL1
NC NO
Diagram “M”
Universal process / counter / frequency
/ integrator / totaliser indicator
Lower Terminals
(Mother board)
Upper Terminals
(Option boards)
19 20 25 26 27 2813 14 15 16 17 18 21 22 23 24
N(+) L(-)
123456789101112
AL2 AL3
AL1
AL4
+ Voltage output
- Output
+D (Rx)
-D (Tx)
Comms GND
+ Current output
NO NO NONO
Lower Terminals
(Mother board)
Upper Terminals
(Option boards)
19 20 25 26 27 2813 14 15 16 17 18 21 22 23 24
N(+) L(-)
123456789101112
Declaration of Conformity
Type : 4001,4011,5001,5011,5600,8001,5001-T,8001-T
Options : 3000 to 3028
Corresponds to the requirements of the following EC directives:
EMC directive : 89/336/EEC
Low voltage directive : 73/23/EEC
The applicable harmonised standards are : EN 50081-1
: EN 50082-1
: EN 61010
The manufacturer reserves the right to alter any specification
without notice.
Guarantee
Page 20
Manufacturer : Calog
The manufacturer undertakes to replace without charge all
defective equipment which is returned to it (transportation costs
prepaid) during the period of guarantee, provided there is no
evidence that the equipment has been abused or mishandled in any
way.
This product is guaranteed against faulty workmanship or defective
material, for a period of 2 (two) years from date of delivery.
