0 - 20 mA, 4 - 20 mA, 0 - 200mV, 0 - 2 V, 0 - 10 V, 0 - 20 V, Special
(pot input), 0.2Hz - 40kHz (24V max, up to 0.01 Hz resolution).
Electrical Specifications
Sensor Excitation
Accuracy & linearity : 0.05% of F.S., or 1 count
Option 3011/15/27 accuracy : 0.5% of F.S., or 1 count
Internal resolution : 20000 counts (bi-polar)
Temperature coefficient : 20 ppm / °C typical
Settling time for process inputs : 0.5 seconds
Settling time for frequency input : 5 milliseconds (with no filter)
Operating temperature range : -10 to +50°C
Storage temperature range: -40 to +80°C
Humidity : < 85% non-condensing
Warm-up time : None required
Electro-mechanical relays : 250V AC, 30V DC, 2A, PF=1
Solid state relays : 400 V AC/DC, 0.5A, PF=1
Analogue output accuracy : 0.1% of full scale, 12 bits
Current analogue output load : 500
W maximum
Voltage analogue output load : 1 k
W minimum
Memory retention : Full non-volatile operation
Option 3006 isolation rating : 1500 V
Declaration of conformity : See last page
24V DC: (17-26V), current limited. For 2-wire transmitters,
proximity switches or encoders. With option 3010,
current capability increases to 100mA
5V DC: ± 1%, maximum 25mA
2.5V DC: Precision reference, 2mA max for pot (2 k
W min)
Input Ranges
The Models 4001, 4011, 5001, 5011, 5600, 8001, 5001-T, 8001-T
indicators are universal LED process indicators that can be
applied to most process variables with analog & digital inputs.
These high accuracy panel meters are designed for accurate
measurement & display of pressure, level, flow, freq, up & down
counting, DC voltages or currents & revolutions / min. Selected
models offer integration / totalisation of the input signal. The built-
in sensor excitation supply is link selectable for 2-wire / 3-wire
transmitters, encoders & potentiometer input.
Model 4001 is a 4 digit (-1999 to 9999) indicator offering process
inputs of type mA, mV, V, pot and frequency.
Model 5001 is a 5 ½ digit (-199999 to 199999) indicator offering all
the features of Model 4001 but with process x frequency functions
as well as count rate & totaliser.
Model 5600 is a 6 digit (-199999 to 999999) indicator offering all
the features of Model 5001. Set points and other options are
however limits to 5 ½ digits.
Model 5001-T is a 5 ½ digit (-199999 to 199999) indicator offering
all the features of Model 5001 but with process integration /
totalisation included.
Model 8001 is a 5 ½ digit rate display indicator with an 8 digit count
display, while the Model 8001-T has process integration /
totalisation included.
Model 4011 & Model 5011 offer Asciibus serial input for remote
display of serial information.
Introduction
Page 3
