Programmable Specifications
5½ / 6 / 8 Digit Models
Zero & full scale setting : -199999 to 199999
Decimal point : Adjustable on all digits
Process filtering : 0.0 to 10.0 seconds
Freq / counter scaler : 0.05 to 1999.99
Frequency units : Selectable Hz or RPM
Frequency filtering : None, 0.5, 1.1 or 4.5 seconds
Counter features : Reset (count up) / Preset (count down),
: Counter rate & totaliser
Options :
Analog output zero & span : -199999 to 199999
Alarm setpoint values : -199999 to 199999
Alarm hysteresis : 0 to 255 (default 1)
Alarm delay : 0 to 255 seconds (default 0)
Alarm relay settings : Selectable HIGH or LOW alarm
Alarm relay state : Selectable NO or NC
Unit address : 0 to 99
Baud rate : 2400, 4800, 9600, 19200
Standard
115 / 230 VAC ± 10%, link selectable, 50/60Hz, 5VA typ
Optional
8 - 30VDC isolated power supply (Option 3008), 5VA typ
8 - 30VDC non-isolated, 5VA typ
95V-265V AC/DC isolated power supply (Option 3010), 5VA typ
Power Supply
4 Digit Models
Zero & full scale setting : -1999 to 9999
Decimal point : Adjustable on all digits
Freq / counter scaler : 00.01 to 99.99
Frequency units : Selectable Hz or RPM
Frequency filtering : None, 0.5, 1.1 or 4.5 seconds
Counter features : Reset (count up) / Preset (count down)
Options :
Analog output zero & span : -1999 to 9999
Alarm setpoint values : -1999 to 9999
Alarm hysteresis : 0 to 255 (default 1)
Alarm delay : 0 to 255 seconds (default 0)
Alarm relay settings : Selectable HIGH or LOW alarm
Alarm relay state : Selectable NO or NC
Unit address : 0 to 99
Baud rate : 2400, 4800, 9600, 19200
Other Specifications
DIN 48 x 96 housing, 147mm depth
Industrial strength single piece housing
Housing is flame retardant ABS plastic that meets UL94 V-0
Circuit board is flame retardant material that meets UL94 V-0
Front facia rating : IP65 (with o-ring seal supplied as standard)
