Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi
®
standard)
5 GHz/2.4 GHz band
BLUETOOTH Section
Communication system
BLUETOOTH Specication version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Frequency Hopping Spread Spectrum)
Compatible BLUETOOTH proles
A2DP 1.2
AVRCP 1.3
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (*)
* The actual range will vary depending on factors such as obstacles between
devices, magnetic elds around a microwave oven, static electricity,
cordless phone, reception sensitivity, antenna's performance, operating
system, software application, etc.
General
Power Supply
AC 120 V, 60 Hz (North American)
AC 220 - 240 V, 50/60 Hz (Others)
Power Consumption
460 W (North American)
450 W (Others)
0.15 W (Full Standby mode)
1.8 W (Network Standby (wired)) (North American)
1.9 W (Network Standby (wired)) (Others)
2 W (Network Standby (wireless))
1.7 W (Bluetooth Wakeup) (North American)
1.8 W (Bluetooth Wakeup) (Others)
0.15 W (HDMI CEC)
2.1 W (Standby mode (ALL ON)) (North American)
2.3 W (Standby mode (ALL ON)) (Others)
55 W (No-sound)
6 W (HDMI Standby Through) (North American)
6.1 W (HDMI Standby Through) (Others)
Dimensions (W × H × D)
435 mm × 174 mm × 376.5 mm
17-1/8" × 6-7/8" × 14-13/16"
Weight
9.6 kg (21.2 lbs.) (North American)
9.8 kg (21.6 lbs.) (Others)
HDMI
Input
IN1 (BD/DVD), IN2 (GAME), IN3 (CBL/SAT), IN4 (STRM BOX), IN5 (PC),
IN6
Output
OUT MAIN (ARC), OUT ZONE 2/SUB
Supported
Deep Color, x.v.Color™, Lip Sync, Audio Return Channel, 3D,
4K 60 Hz , CEC, Extended Colorimetry (sYCC601, Adobe RGB, Adobe
YCC601), Content Type, HDR (HDR10, BT.2020, HLG), Dolby Vision
