Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS, DTS:X,
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS Express, DSD, PCM
HDCP version
2.2
Maximum Video Resolution
4K 60 Hz (YCbCr 4:4:4)
Video Inputs
Component
IN1 (BD/DVD)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX), AUX (front)
Supported input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
• Signals are output from the HDMI OUT jack of this unit to the TV with the
same resolution as the input resolution. When using a TV that supports 4K,
1080p HDMI video signals can also be output as 4K.
Audio Inputs
Digital
OPTICAL (TV)
COAXIAL (BD/DVD)
Analog
BD/DVD, CBL/SAT, STRM BOX, CD, PHONO, AUX (front)
Audio Outputs
Analog
ZONE B LINE OUT
2 SUBWOOFER PRE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R or SURROUND
BACK L/R, ZONE 2 L/R (North American models are compatible with
banana plugs.)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
Others
Setup Mic: 1 (Front)
USB: 1 (Ver. 2.0, 5 V/1.0 A)
Ethernet: 1
RS232 : 1
IR IN : 2 (A/B)
IR OUT : 1
12V TRIGGER OUT : 3 (A:100 mA, B:25 mA, C:25 mA)
Specications and features are subject to change without notice.
