Integra DRX-7.1 User Manual

27
> Specifications > Advanced Setup > Listening Modes
> Network Functions > Basic Manual
|Troubleshooting Supplementary Information, etc.
Setting Item Default Value Setting Details
GAME Main
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
GAME
" is selected as input
for main room.
"Zone 2": Output when "
GAME
" is selected as input
for ZONE2.
"Main/Zone 2": Output when "
GAME
" is selected as
input for main room or ZONE2
.
"
Zone 3
"
: Output when
"GAME"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"GAME"
is selected as
input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"GAME"
is selected
as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"GAME"
is selected as input for main room, ZONE2 or
ZONE3.
STRM BOX Main
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
STRM BOX
" is selected as
input for main room.
"Zone 2": Output when "
STRM BOX
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
STRM BOX
" is
selected as input for main room or ZONE2
.
"
Zone 3
"
: Output when
"STRM BOX"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"STRM BOX"
is
selected as input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"STRM BOX"
is
selected as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"STRM BOX"
is selected as input for main room, ZONE2 or
ZONE3.
Setting Item Default Value Setting Details
PC Main
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
PC
" is selected as input for
main room.
"Zone 2": Output when "
PC
" is selected as input for
ZONE2.
"Main/Zone 2": Output when "
PC
" is selected as
input for main room or ZONE2
.
"
Zone 3
"
: Output when
"PC"
is selected as
input
for
ZONE3.
"
Main/Zone 3
"
: Output when
"PC"
is selected as
input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"PC"
is selected as
input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"PC"
is
selected as input for main room, ZONE2 or
ZONE3.
AUX Main
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
AUX
" is selected as input for
main room
.
