Front & Rear Panels
For detailed information, see the pages in
parentheses.
a 8On/Standby button (23)
b Bluetooth indicator (33, 80)
c Wi-Fi indicator (29)
d Hybrid Standby indicator (24)
e Monitor Out button (60)
f Remote control sensor (11)
g Tone and Tone Level buttons (56, 57, 84)
h Display (8)
i Listening Mode buttons (43)
j Dimmer button (North American models) (51)
k Memory button (40)
l Tuning Mode button (40)
m Display button (51)
n Home button (54)
o Tuning q/w (40), Preset e/r (40), cursor and
Enter buttons
p Return button
q Master Volume control (31)
r Zone 2/Zone 3 and Off buttons (83)
s Whole House Mode and Off buttons (52)
t Phones jack (22)
u Setup Mic jack (27)
v Input selector buttons (31)
w USB port (34)
x AUX Input jacks (18)
y RT/PTY/TP button (Australian models) (41)
Front Panel
(North American models) (Australian models)
afeh
g jkl
nmop qc
vxtsurw
ibd
y
