Advanced Operations
En-63
Operating procedure (➔ page 59)
Here you can check the settings made by
Audyssey MultEQ
®
XT32 Room Correction and
Speaker Setup function, or set them manually, which
is useful if you change one of the connected speakers
after using Audyssey MultEQ XT32 Room Correction
and Speaker Setup function (➔ page 26).
Note
• These settings are not available in either of the following
cases:
– a pair of headphones is connected.
– The “Audio TV Out (HDMI)” setting is set to “On”
(➔ page 78) or “Audio TV Out (HDBaseT(TM))” setting
is set to “On” (➔ page 78) and you’re listening through
your TV speakers.
–“HDMI CEC (RIHD)” is set to “On” (➔ page 77) and
you’re listening through your TV speakers.
Speaker Settings
If the impedance of any speaker is 4 ohms or more
but less than 6, set the minimum speaker impedance
to 4 ohms.
If you bi-amp the front speakers, you must change the
“Speakers Type(Front)” setting. For details on
speaker wire connection, see “Bi-amping the Front
Speakers” (➔ page 15). When connecting speakers
without crossover network, you need to change the
“Speakers Type(Front)” setting beforehand. For
details on connection, refer to “Using Speakers
Without Crossover Network” (➔ page 16).
Note
• When bi-amping is used, the AV receiver is able to drive up
to 7.1 speakers in the main room.
• Before you change these settings, turn down the volume.
■ Speaker Impedance
` 4ohms:
Select if the impedance of any speaker is
4 ohms or more but less than 6.
` 6ohms
:
Select if the impedances of all speakers are
between 6 and 16 ohms.
■ Speakers Type(Front)
` Normal
:
Select this if you’ve connected your front
speakers normally.
` Bi-Amp:
Select this if you’ve bi-amped your front
speakers.
` Digital Crossover:
Select this if you’re using speakers without
crossover network.
Tip
• If “Speakers Type(Front)” is set to “Digital Crossover”, a
confirmation screen appears. Select “Next (2-7. Digital
Processing Crossover Network)” to display the screen
for Digital Processing Crossover Network (➔ page 66).
Continue with the settings.
■ Powered Zone 2, Powered Zone 3
` No
` Yes:
Zone 2/3 speakers can be used (Powered
Zone 2/3 enabled).
■ 11ch Playback
` No
` Yes
For 11.1-channel playback, set this setting to “Yes”. If
you select front wide speakers setting in Speaker
Configuration is set to “None”, it will be automatically
switched to “80Hz (THX)”.
Note
• Powered Zone 3 is not available in the following cases:
–The “Speakers Type(Front)” setting is set to “Bi-Amp” or
“Digital Crossover”.
–The “Powered Zone 2” setting is set to “No”.
• When the “Powered Zone 3” setting is set to “Yes” while
Powered Zone 2 is enabled (➔ page 83), the surround
back speakers cannot be used.
• When the “Powered Zone 2” setting is set to “Yes”, the
front wide speakers cannot be used.
• When the “Powered Zone 3” setting is set to “Yes”, the
front high speakers cannot be used.
•“11ch Playback” is not available in the following cases:
–The “Speakers Type(Front)” setting is set to “Bi-Amp” or
“Digital Crossover”.
–The “Powered Zone 2” setting is set to “Yes”.
–The “Zone 2 Monitor Out” setting is set to
“HDBaseT(TM)”.
• If the “11ch Playback” setting is set to “Yes”, the audio of
front wide channel is output from FRONT WIDE PRE OUT
only.
Speaker Configuration
With these settings, you can specify which speakers
are connected and a crossover frequency for each
speaker. Specify “Full Band” for speakers that can
output low frequency bass sounds adequately, for
example, speakers with a good sized woofer. For
smaller speakers, specify a crossover frequency.
Sounds below the crossover frequency will be output
by the subwoofer instead of the speaker. Refer to
your speaker’s manuals to determine the optimum
crossover frequencies. If you set up your speakers
using Audyssey MultEQ XT32 Room Correction and
Speaker Setup, please make sure manually that any
THX speakers are set to “80Hz(THX)” crossover.
2. Speaker Setup
If you change these settings, you must run
Audyssey MultEQ XT32 Room Correction and
Speaker Setup again (➔ page 26).
This setting is set automatically by
Audyssey MultEQ XT32 Room Correction and
Speaker Setup function (➔ page 26).
To Next Page
