Integra DTR-7.4 Service Manual

REF. NO. PART NO. DESCRIPTION
88 27150474 Shield
p
late, wire
89 27150485 Shield
p
late
90 27150470 Shield
p
late, fan
91 27270438 t0.5xφ8xφ3.2,S
p
acer
92 29110083 Ta
p
e, cloth
94 87643010 W3*10F
(
BC
)
,Washer
95 260258 Wire tie
96 260208 Wire tie
97 8631901 N-9F
(
P 0.75
)
,Nut
99 223025 AC262,Isolated
p
late
100 24502310 D09T-24PG10
(
EX
)
,Fan
104 29363195 Label, hooku
p
<D>
108 29363264 Label MAC
110 28141520A t6.5x40x25,Cushion
F6901,F6902 252199 ! 10A-UL,Fuse <D>
252100 ! 10A-EAK,Fuse <A>
F901 252199 ! 10A-UL,Fuse <D>
F902 252077, ! 4A-SE-EAK,
252243 or ! 4A-SE-TL250V or
252277 ! 4A-SE-TL250V <A>
F903 252164 or ! 5A-UL/T-237 o
r
252258 ! 5A-T/UL-ST2,Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V,Fuse <A>
F9501,F9502 252160 or ! 2.5A-UL/T-237 o
r
252254 ! 2.5A-T/UL-ST2,Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V,Fuse <A>
F9501A 29363313 ! T2.5AL1.6AL250V, Label, fuse <A>
F9503,F9504 252158 or ! 1.6A-UL/T-237 o
r
252252 ! 1.6A-T/UL-ST2,Fuse <D>
252073, ! 1.6A-SE-EAK,
252239 or ! 1.6A-SE-TL250V or
252273 ! 1.6A-SE-TL250V,Fuse <A>
P1010 2047151012 NCFC7-151012,Flat cable
P2901 2047191012 NCFC7-191012,Flat cable
P6009 27141825 Retainer, bus
P602 2009990753UL NSAS-8P1059,Socket
P603 204406027 NCFC4-062512,Flat cable
P6205 27141826 Retainer, bus
P7201 2047312512 NCFC7-312512,Flat cable
P7701 2047051012 NCFC7-051012,Flat cable
Q6050~Q6056 2202823 or * 2SC5200-O o
r
2202822 * 2SC5200-R,Transistor
Q6060~Q6066 2202813 or * 2SA1943-O o
r
2202812 * 2SA1943-R,Transistor
T901 2301715 ! NPT-1482D,Power transformer <D>
2301654 ! NPT-1454P,Power transformer <A>
U1 1A995546-2H NADIS-7746-2H,Dis
p
la
y
circuit PC board ass'
y
<D>
1A995546-2J NADIS-7746-2J,Dis
p
la
y
circuit PC board ass'
y
<A>
U2 1A995547-2H NAETC-7747-2H,Standb
y
switch PC board ass'
y
<D>
1A995547-2J NAETC-7747-2J,Standb
y
switch PC board ass'
y
<A>
U3 1A995548-2H NAETC-7748-2H,Master volume PC board ass'
y
<D>
1A995548-2J NAETC-7748-2J,Master volume PC board ass'
y
<A>
U4 1A995549-2H NAETC-7749-2H,Hed
p
hone terminal PC board ass'
y
<D>
1A995549-2J NAETC-7749-2J,Hed
p
hone terminal PC board ass'
y
<A>
U5 1A996521-2Q NAETC-7721-2Q,Front video PC board ass'
y
U6 1A996522-2Q NAETC-7722-2Q,O
p
tical in
p
ut PC board ass'
y
U7 1A996587-2P NADG-7687-2P,DSP circuit PC board ass'
y
U8 1A996562-3 NADG-7662-3,Net-tune PC board ass'
y
U11 1A996518-2Q NAAF-7718-2Q,Pream
p
lifier PC board ass'
y
U12 1A996519-2Q NAAF-7719-2Q,Audio terminal PC board ass'
y
U13 1A996520-2Q NAAF-7720-2Q,Video terminal PC board ass'
y
U14 1A996523-2Q NAETC-7723-2Q,PC board for holder
U15 1A996524-2Q NAETC-7724-2Q,PC board for holder
