Integra DTR-7.4 Service Manual

REF. NO. PART NO. DESCRIPTION
U21 1A996506-2M NAAF-7706-2M,Power am
p
lifier PC board ass'
y
<D>
1A996506-2N NAAF-7706-2N,Power am
p
lifier PC board ass'
y
<A>
U22 1A996507-2M NAAF-7707-2M,Driver circuit PC board ass'
y
<D>
1A996507-2N NAAF-7707-2N,Driver circuit PC board ass'
y
<A>
U23 1A996508-2M NAPS-7708-2M,Constant volta
g
e PC board ass'
y
<D>
1A996508-2N NAPS-7708-2N,Constant volta
g
e PC board ass'
y
<A>
U24 1A996514-2N NAETC-7714-2N,Thermal detector PC board ass'
y
<A>
U26 1A996590-2T NAAF-7690-2T,F/C driver circuit PC board ass'
y
<D>
1A996590-2U NAAF-7690-2U,F/C driver circuit PC board ass'
y
<A>
U27 1A996591-2T NAPS-7691-2T,Primar
y
circuit PC board ass'
y
<D>
1A996591-2U NAPS-7691-2U,Primar
y
circuit PC board ass'
y
<A>
U28 1A996592-2T NAPS-7692-2T,Bias selector PC board ass'
y
<D>
1A996592-2U NAPS-7692-2U,Bias selector PC board ass'
y
<A>
U30 1A996594-2T NAETC-7694-2T,S
p
eaker terminal PC board ass'
y
<D>
1A996594-2U NAETC-7694-2U,S
p
eaker terminal PC board ass'
y
<A>
U31 1A996595-2T NAETC-7695-2T,Surround s
p
eaker terminal PC board ass'
y
<D>
1A996595-2U NAETC-7695-2U,Surround s
p
eaker terminal PC board ass'
y
U32 1A996596-2T NAETC-7696-2T,Fan drive circuit PC board ass'
y
<D>
1A996596-2U NAETC-7696-2U,Fan drive circuit PC board ass'
y
<A>
U33 1A996597-2U NAETC-7697-2U,Thermal detector PC board ass'
y
<A>
U35 1A996500-2T NAETC-7700-2T,AC inlet PC board ass'
y
<D>
1A996500-2U NAETC-7700-2U,AC inlet PC board ass'
y
<A>
U36 1A996501-2U NAETC-7701-2U,PC board for holder <A>
U37 1A996502-2T NAETC-7702-2T,PC board for holder <D>
1A996502-2U NAETC-7702-2U,PC board for holder <A>
U41 1A996578-1P NAAR-8078-1P,Main connector PC board ass'
y
<D>
1A996578-1Q NAAR-8078-1Q,Main connector PC board ass'
y
<A>
U42 1A996579-1P NAVD-8079-1P,Com
p
onent video PC board ass'
y
<D>
1A996579-1Q NAVD-8079-1Q,Com
p
onent video PC board ass'
y
<A>
U45 1A996583-1P NAETC-8083-1P,Control terminal PC board ass'
y
<D>
1A996583-1Q NAETC-8083-1Q,Control terminal PC board ass'
y
<A>
U47 1A996585-1P NAETC-8085-1P,Thermal detector PC board ass'
y
<D>
U48 1A996586-1P NAETC-8086-1P,Thermal detector PC board ass'
y
<D>
U51 1A996569-1L NAVD-8069-1L,S video PC board ass'
y
<D>
1A996569-1M NAVD-8069-1M,S video PC board ass'
y
<A>
U52 1A996570-1L NAVD-8070-1L,Com
p
onent video PC board ass'
y
<D>
1A996570-1M NAVD-8070-1M,Com
p
onent video PC board ass'
y
<A>
U55 1A996573-1L NAETC-8073-1L,S video PC board ass'
y
<D>
1A996573-1M NAETC-8073-1M,S video PC board ass'
y
<A>
U61 240146, FAE385-A02F,
240134A or TFCE1U114B o
r
240138A ENG06501QR,Tuner
p
ack <D>
240147, FAE485-E02F,
240135 or TFCE1E512A or
240139A ENG07501QR,Tuner
p
ack <A>
