A
TERMINAL DESCRIPTION(3/5)
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -19
Q3401, Q3501: D790E001BZDH300 (Audio DSP)
TX-SR806/SA806
BALL
SIGNAL NAME TYPE
(1)
PULL
(2)
GPIO
(3)
DESCRIPTION
NO.
External Memory Interface (EMIF) Data Bus / Universal Host-Port Interface (UHPI) Address Bus Option
EM_D[0] T8 IO - N
EM_D[1] R8 IO - N
EM_D[2] R7 IO - N
EM_D[3] T6 IO - N
EM_D[4] R6 IO - N
EM_D[5] T5 IO - N
EM_D[6] R5 IO - N
EM_D[7] T4 IO - N
EMIF Data Bus [Lower 16 Bits]
EM_D[8] R13 IO - N
EM_D[9] T12 IO - N
EM_D[10] R12 IO - N
EM_D[11] T11 IO - N
EM_D[12] R11 IO - N
EM_D[13] R10 IO - N
EM_D[14] T9 IO - N
EM_D[15] R9 IO - N
EM_D[16]/UHPI_HA[0] N7 IO/I IPD N
EM_D[17]/UHPI_HA[1] P6 IO/I IPD N
EM_D[18]/UHPI_HA[2] N6 IO/I IPD N
EM_D[19]/UHPI_HA[3] P5 IO/I IPD N
EM_D[20]/UHPI_HA[4] P4 IO/I IPD N
EM_D[21]/UHPI_HA[5] P3 IO/I IPD N
EM_D[22]/UHPI_HA[6] N4 IO/I IPD N
EM_D[23]/UHPI_HA[7] R2 IO/I IPD N
EMIF Data Bus [Upper 16 Bits (IO)] or
UHPI Address Input (I)
EM_D[24]/UHPI_HA[8] P11 IO/I IPD N
EM_D[25]/UHPI_HA[9] N11 IO/I IPD N
EM_D[26]/UHPI_HA[10] P10 IO/I IPD N
EM_D[27]/UHPI_HA[11] N10 IO/I IPD N
EM_D[28]/UHPI_HA[12] P9 IO/I IPD N
EM_D[29]/UHPI_HA[13] N9 IO/I IPD N
EM_D[30]/UHPI_HA[14] N8 IO/I IPD N
EM_D[31]/UHPI_HA[15] P7 IO/I IPD N
