Intel Agilex I Series User Manual

The following sections describe the Clock Controller buttons.
Read
Reads the current frequency setting for the oscillator associated with the active tab.
Default
Sets the frequency for the oscillator associated with the active tab back to its default
value. This can also be accomplished by power cycling the board.
Set
Sets the programmable oscillator frequency for the selected clock to the value in the
OUTx output controls for the Si5391. Frequency changes might take several
milliseconds to take effect. You might see glitches on the clock during this time. Intel
recommends resetting the FPGA logic after changing frequencies.
Import
Si5391 has a two-time writable non-volatile memory (NVM). You can generate the
register list from the Clockbuilder Pro tool and import it into Si5391 to update the
settings of the NVM. Register changes are volatile after power cycling.
Clockbuilder Pro Software on Skyworks website
4.4. Monitor On-board Power Regulator through Power Monitor GUI
The Power Monitor GUI reports most power rails’ voltage, current, and power
information on the board. It also collects temperature from FPGA die, power modules,
and diodes assembled on PCB.
Power Monitor GUI communicates with System Intel MAX 10 through either USB port
J8 or 10-pin JTAG header J10. System Intel MAX 10 monitors and controls power
regulator, temperature/voltage/current sensing chips through a 2-wire I
2
C bus.
The instructions to run Power Monitor GUI are stated in the Run BTS GUI on page 24.
It can also be started with the BTS GUI icon “Power”.
Note: You cannot run the stand-alone Power Monitor GUI when the BTS or the Clock
Controller GUI is running at the same time.
4. Board Test System
683288 | 2022.09.22
Intel
®
Agilex
™
I-Series FPGA Development Kit User Guide
Send Feedback
36
