Intel Agilex I Series User Manual

1. Overview
This user guide describes the design features and the usage of the Intel
®
Agilex
™
I-
Series FPGA Development Kit board.
Table 1. Intel Agilex I-Series FPGA Development Kit Ordering Information
Ordering Code Device Part Number
DK-DEV-AGI027RES AGIB027R29A1E2VR0
DK-DEV-AGI027R1BES AGIB027R29A1E2VR3
For the board and FPGA capabilities, refer to the Intel Agilex FPGA and SoC page on
the Intel website.
For more information about the Intel Agilex Device Errata Sheet and User Guidelines
(ES-1069) and Intel Agilex Known Issue List, contact Intel Premier Support and quote
ID #15011992053.
1.1. Block Diagram
The demonstration board showcases the features of the Intel Agilex I-Series device in
the F2957 FBGA package. These devices feature R-tile transceivers with PCIe* Gen5
x16 and CXL
(1)
interfaces and F-tile transceivers with 28G x8 or 56G x8 QSFPDD
interfaces. The board supports two on-board DDR4 x72 with ECC channels. The board
also features a dual DIMM memory channel for DDR4 and DDR-T.
(1)
To activate the CXL hard IP and receive CXL soft R-Tile Wrapper and Soft Support logic,
purchase or activation of a separate CXL IP license is required for proper use with the Intel
Quartus
®
Prime Design Software. Contact your local Intel sales representative for pricing
details. To activate a free-of-charge 30- or 60-days trial IP license, please contact your local
Intel sales representative.
