A.2. Intel Agilex I-Series FPGA
Intel Agilex I-Series FPGA 56 mm x 45 mm package:
• Part Number: AGIB027R29A1E2VR0 or AGIB027R29A1E2VR3
• 2957-Ball FBGA Package
• 2.7M LEs
• 8528 digital signal processing (DSP) blocks
• 17056 18x19 Multipliers
• LVDS pairs supporting 1.6 Gbps
• 3x R-tile supporting PCIe Gen5 x16 (32Gb/s) or CXL
(2)
x16
• 1x F tile transceiver supporting 56Gbps NRZ
A.3. PCIe and CXL Interfaces
The Intel Agilex I-Series FPGA Development Kit supports two PCIe/CXL Gen5 x16
interfaces using two out of the FPGA's three R-tiles, refer to Figure 1 on page 5.
1. One R-tile (14C) supports PCIe/CXL x16 connecting to the development kit's PCIe
edge connector. This interface supports x1, x4, x8, and x16 PCIe Endpoint or CXL
Endpoint.
2. One R-tile (15C) connects to two 74-pin MCIO connectors that can be used as CXL
or PCIe x16 interface in the Endpoint or Root Port mode. The MCIO connectors
also carry SMBus/I2C, clock, and GPIO signals.
Note: To activate the CXL hard IP and receive CXL soft R-Tile Wrapper and Soft Support
logic, purchase or activation of a separate CXL IP license is required for proper use
with the Intel Quartus Prime Design Software. Contact your local Intel sales
representative for pricing details. To activate a free-of-charge 30- or 60-days trial IP
license, please contact your local Intel sales representative.
A.4. MCIO Connector
The CXL or PCIe interface is connected to two 74-pin MCIO connectors for 16 channels
of transmit and receive signals of the R-tile (15C). Cables are used to connect this CXL
or PCIe link from the development kit to the host board or application-specific
daughter cards.
(2)
To activate the CXL hard IP and receive CXL soft R-Tile Wrapper and Soft Support logic,
purchase or activation of a separate CXL IP license is required for proper use with the Intel
Quartus Prime Design Software. Contact your local Intel sales representative for pricing details.
To activate a free-of-charge 30- or 60-days trial IP license, please contact your local Intel sales
representative.
A. Development Kits Components
683288 | 2022.09.22
Intel
®
Agilex
™
I-Series FPGA Development Kit User Guide
Send Feedback
42
