Page #7 background image
1.2. Box Contents
Intel Agilex I-Series FPGA Development board, DDR4 DIMM module, USB2.0 Micro-
USB cable, 240W power adapter, and NA/EU/JP/UK cords.
Note: Intel provides only one DIMM module with each development kit.
1.3. Operating Conditions
Table 2. Recommended Operating Conditions
Operating Condition Range
Recommended ambient operating temperature range 0°C to 35°C
Maximum ICC load current 198 A
Maximum ICC load transient percentage 30%
Maximum FPGA power supported by the supplied
heatsink/fan
180 W
Handling Precautions
When handling the board, observe static discharge precautions.
Caution: Without proper anti static handling, the board can be damaged. Therefore, use anti-
static handling precautions when touching the board.
Caution: This development kit should not be operated in a vibration environment.
1. Overview
683288 | 2022.09.22
Send Feedback
Intel
®
Agilex
I-Series FPGA Development Kit User Guide
7
